销售倍加福P+F漫反射型传感器,GLK18-8-200/25/161/166

销售倍加福P+F漫反射型传感器,GLK18-8-200/25/161/166

电话；021-39529839转8012

传真；021-39529830-8007

企业QQ；2880626085

手机；18918574312

邮箱；18918574312@163.com

联系人；方海燕

信号输出N-channel MOSFET, short circuit protected

产品标准EN 60947-5-2:2007 ; IEC 60947-5-2:2007

连接器Micro AC connector, 1/2" V124 ; 4-pin

Efficient Line in a short M18 plastic housing

 for standard applications

光斑直径approx. 15 mm at 200 mm

功能显示LED yellow: lights when object is detected ;

flashes when falling short of the stability control

输出开关类型（显示屏）常亮360°全方位可视的4个LED指示器

Optimized potentiometer design for a clear

control button layout in the application

Universal usage at different power suppliesfuse

mode sensor, M18 threaded housing design,

plastic housing, front optical face, 200 mm

detection range, red light, light ON, AC/DC

 version, NPN-FET output, micro plug

检测距离20 ... 200 mm adjustable

光源类型modulated visible red light , 640 nm

销售倍加福P+F漫反射型传感器,GLK18-8-200/25/161/166
