液压操作的节流阀贺德克进口品牌，SDH 05330-01X

液压操作的节流阀贺德克进口品牌，SDH 05330-01X

概述：

into throttle position when control pressure is applied.

The hydraulically actuated needle valve SDH05330

open position which move into throttle

 Cavity (metric) M 20 x 1.5. Qmax = 20 l/min Pmax = 250 bar

position when charged by hydraulic stress.

 From completely open position, the valve moves

are direct acting valves with initially fully

is a valve with throttle spindle and turning screw.

HYDAC needle valves with hydraulic actuation

Flow control is dependent on the viscosity

特点：

of the oil and the system pressure

A lock-nut locks the setting

minimal wear and extended service life

Compact design

External surfaces zinc-plated

Hardened and ground control piston to ensure

技术参数：

Ambient temperature range: min. -20 °C to max. +100 °C

Filtration: Class 21/19/16 to ISO 4406 or cleaner

Media operating temperature range: min. -20 °C to max. +100 °C

Operating pressure: max. 250 bar

Operating fluid: Hydraulic oil to DIN 51524 Part 1 and 2

Viscosity range: min. 10 mm²/s to max. 380 mm²/s

Nominal flow: max. 20 l/min

Control pressure: min = P at Port 2 + 5 bar, max. 250 bar
