费斯托减速机 DSBC-125-400-PPVA-N3工作原理概述

费斯托减速机 DSBC-125-400-PPVA-N3工作原理概述

  • 所属分类:FESTO(费斯托)气缸
  • 浏览次数:
  • 发布日期:2021-03-18
  • 产品概述
  • 性能特点
  • 技术参数

费斯托减速机 DSBC-125-400-PPVA-N3工作原理概述

Technical data

Gear unit size [mm] @ 40 @ 60

Gear ratio [i] 3 5 8 12 20 3 5 8 12 20

Output interface 40G 60H

Motor interface 40P 60P

Gear unit type Right-angle gear unit

Single-stage Two-stage Single-stage Two-stage

Continuous output torque1) [Nm] 4.5 7.5 6 20 14 24 18 44

Max. output torque2) [Nm] 7 12 10 32 22 38 29 70

Max. drive speed [rpm] 18000 13000

Torsional rigidity [Nm/arcmin] 0.8 0.7 0.8 2 1.9 1.6 2

Torsional backlash [deg] 0.35 0.41 0.27 0.3

Mass moment of inertia3) [kgcm2] 0.049 0.035 0.032 0.048 0.035 0.394 0.257 0.243 0.391 0.256

Max. efficiency [%] 95 92 94 92 95 93 94 92

Operating temperature4) [°C] –25 ... +90

Degree of protection IP54

Product weight [g] 500 600 1700 1900

Note on materials RoHS-compliant

Gear unit size [mm] @ 80

Gear ratio [i] 3 5 8 12 20

Output interface 80G

Motor interface 80P, 100A

Gear unit type Right-angle gear unit

Single-stage Two-stage

Continuous output torque1) [Nm] 40 67 50 120

Max. output torque2) [Nm] 64 107 80 192

Max. drive speed [rpm] 3500 3600 3800 2650 3550

Torsional rigidity [Nm/arcmin] 5 4.8 4.2 5 5.1

Torsional backlash [deg] 0.22 0.22 0.25

Mass moment of inertia3) [kgcm2] 1.409 1.017 0.934 1.379 1.013

Max. efficiency [%] 95 94 94 93

Operating temperature4) [°C] –25 ... +90

Degree of protection IP54

Product weight [g] 4300 4400 5000
