OMRON中间继电器G2R-2-SND DC24(S) BY OMB

OMRON中间继电器G2R-2-SND DC24(S) BY OMB

与Push-In Plus插座型P2RF-□-PU组合使用，可缩短60%配线工时(本公司实测值数据) 线圈-接点之间的耐电压为5,000V，

耐浪涌电压为10,000V 的安全设计。

 通过对AC/DC线圈胶带颜色的改变，大大提高了AC/DC规格的识别性。

新增了便于检查回路的带闭锁摆杆型(G2R-□-S(S))。

■额定线圈电流:43.6mA

 ■线圈直流电阻:275欧

■动作电压:<额定线圈电压的70%

■复位电压:>额定线圈电压的15%

■电压大值:额定线圈电压的120%

 ■功率消耗:530mW

外形尺寸(mm): 29.0×13.0×22.5mm(L×W×H)

重 量 : 17g

触点参数:

触点形式: 2C(DPDT)

触点负载: 10A 250VAC 10A 30VDC

阻 抗: ≤30mΩ

额定电流: 10A

电气寿命:≥10万回

机械寿命:≥1000万回

线圈参数:

阻值(士10%):1100Ω

线圈功耗:530mW

额定电压:DC 24V

吸合电压:DC 16.8 V

释放电压:DC 3.6V

工作温度:-40℃~+70℃

绝缘电阻:≥1000MΩ

线圈与触点间耐压:5000VAC/1分钟

触点与触点间耐压:1000VAC/1分钟
