派克D31FHE02C1NB00比例切换阀D31FCE02DC1NB70

派克D31FHE02C1NB00比例切换阀D31FCE02DC1NB70

端口连接: NG10 / CETOP 05

安装类型: 底板安装

阀芯代码: E02

运行类型: 先导式

流速: 90 L/Min

启动类型: 比例电磁铁, Solenoid

功能: 3-way

先导入口/排水位置: Internal/external

重量: 9 kg

大流速: n/a

密封材料: NBR

产品序列: DC比例阀

信号输入: 0-±10 V

大运行压力: 350 bar

流动方向: 0-10 V = P-B

连接类型: 6 + PE + enable

与流体类型共同使用: Hydraulic Oil according to DIN 51524 ... 535, Water-Glycol

阀门选件: Standard

密封材料: NBR

阀体材料: Cast Iron

低环境温度: -20 °C

应用: Industrial Hydraulic

品牌: Parker

技术: Hydraulics

分部: Industrial Systems Division Europe

阀门类型: Proportional DC Valve

介质: Hydraulic Oil

高流体温度: 60 °C

低流体温度: -25 °C

电子类型: Onboard

流速: 90 L/min

大运动粘度: 400 cSt

小运动粘度: 20 cSt

抗振性: 10 Sinus 5...2000 Hz acc. IEC 68-2-6 10 (RMS) Random noise 20...2000 Hz acc. IEC 68-2-36 15 Shock acc. IEC 68-2-27 g

安装位: Unrestricted

开口点变化: set to 10 % command signal

响应时间: 2.9 ms

防护等级: IP65 in accordance with EN 60529

电源电压: 18...30, electric shut-off at < 17, ripple < 5 % eff., surge free V

大先导压力: 350 bar

小先导压力: 20 bar
